What is a carburettor? PH Explains


For an engine to function properly it must be supplied with a regulated mixture of fuel and air. Prior to the advent of affordable and accurate electronic fuel injection systems, manufacturers would typically rely on a device called a carburettor to fulfil this requirement.

The popularity of carburettors was due in part to their straightforward nature, with most consisting effectively of just five key parts - the main body, a float chamber, a fuel discharge nozzle, a 'venturi' and a throttle system.

When you crank a carburettor-equipped engine, the pressure drop created when a piston travels down the cylinder on the intake stroke causes air to be drawn into the carburettor's 'barrel' - an opening that runs through its body. As this air travels into the carburettor's barrel it must pass through the venturi, which contains the discharge nozzle.


For the air to get through the venturi, which is smaller than the primary barrel or 'bore' of the carburettor, it has to speed up. This causes its pressure to fall, to below that of atmospheric levels. Fuel, at atmospheric pressure, is consequently drawn out of the discharge nozzle; this then mixes with the air in the venturi, before being fed into the engine.

The throttle, typically a butterfly valve behind the venturi, controls the engine speed by regulating the flow of air into the engine. With the throttle almost closed, little air - and thus little fuel - is drawn into the engine, and vice versa.

Maintaining the correct fuel pressure at the discharge nozzle is achieved by the use of a float chamber, which functions like the cistern on a toilet. It contains a float, typically brass or plastic, which rises as the chamber fills. When it reaches a level that will result in the correct pressure as the discharge nozzle, it cuts off the fuel supply - and opens it again when the level falls. If the pressure were too high, fuel could be forced into the venturi, upsetting the mixture.


More complicated carburettors will feature multiple barrels, discharge nozzles and other fuel supply ports, regulated by fuel-metering 'circuits' - which are passageways that supply fuel from the float chamber to the discharge points. Typically, they account for different engine speed ranges and can be adjusted, often by the use of screw-in fittings called 'jets'. Some carburettors also have 'accelerator pumps', which deliver a shot of fuel when demand suddenly increases, maintaining smooth operation.

Carburettors are also often equipped with a choke, which usually takes the form of a flap or a butterfly. When in use it restricts the flow of air through the carburettor, increasing the vacuum on the engine side of the venturi and resulting in more fuel being drawn out. This is used to help get the engine started when cold, when myriad factors - such as the temperature being so low as to stop most of the fuel vaporising - are working against it.

A properly maintained carburettor can prove a relatively accurate and straightforward method of delivering fuel - and you'll still find them in applications where simplicity and reliability are key, ranging from garden equipment to light aircraft. Otherwise, in most modern applications, they have been superseded by more accurate, self-adjusting electronic fuel injection systems.

Lewis Kingston

PH Explains Hub

P.H. O'meter

Join the PH rating wars with your marks out of 10 for the article (Your ratings will be shown in your profile if you have one!)

  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
Rate this article

Comments (33) Join the discussion on the forum

  • V8 FOU 17 Jan 2018

    Oh dear.
    Not very good.
    What about cold start systems? Or ones such as the AED?
    Accelerator pump for smooth running? Really? It is to enrichen the mixture under rapid opening of the butterfly, otherwise the mixture would be very weak.

    Temperature compensation?
    "Hedgehogs"?

    Etc......


    Must try harder.

  • S2r 17 Jan 2018

    V8 FOU said:
    "Hedgehogs"?
    My Mk1 Caddy has a 'hedgehog' - it's a series of rounded spikes in the inlet manifold beneath the carb (32/34 weber DMTL with a manual choke if you're interested)



    Edited by S2r on Wednesday 17th January 19:10

  • Mave 17 Jan 2018

    V8 FOU said:
    Oh dear.
    Not very good.
    What about cold start systems? Or ones such as the AED?
    Accelerator pump for smooth running? Really? It is to enrichen the mixture under rapid opening of the butterfly, otherwise the mixture would be very weak
    Must try harder.
    Isn't "rapid opening of the butterfly" similar to "when demand suddenly increases"?

  • V8 FOU 17 Jan 2018

    Mave said:
    V8 FOU said:
    Oh dear.
    Not very good.
    What about cold start systems? Or ones such as the AED?
    Accelerator pump for smooth running? Really? It is to enrichen the mixture under rapid opening of the butterfly, otherwise the mixture would be very weak
    Must try harder.
    Isn't "rapid opening of the butterfly" similar to "when demand suddenly increases"?
    Indeed. Same thing. Still need enrichment, what ever you care to call the situation.

  • TonyRPH 17 Jan 2018

    I suppose as a basic outline it's not a bad article really.

    Given the variations between SU / Stromberg type carbs and Webers for example, where the Webers (and Dellorto) have all manner of extras like auxiliary venturis, emulsion tubes, air correction jets etc.

    The article gives a basic explanation of what happens when you hit the 'loud' pedal.
