Well great great news today, block will be back from the machine shop on Thursday & engine should be in for Monday, dyno work to do & if all goes to plan end of next week ready for shipping
Over the moon - here's final pics from the bodyshop, there will be stainless steel guards going over the holes cut out each side for the exhausts & i think she will look wonderful
Really chuffed with how the car looks & fingers crossed end of June she will be in the UK
A shed load of devlopment work to do over the next couple of years & i need to sort my life out to drive the thing properly !!
Over the moon - here's final pics from the bodyshop, there will be stainless steel guards going over the holes cut out each side for the exhausts & i think she will look wonderful
Really chuffed with how the car looks & fingers crossed end of June she will be in the UK
A shed load of devlopment work to do over the next couple of years & i need to sort my life out to drive the thing properly !!
lol - not going to kill the class mate - one more year for the skyline whilst we try & get our head around this - mainstream events only in 2010.
Engine is useful puny jap crap but putting out some mighty decent bhp
As for the driver, god help us - well have already bought 12 pairs of spare pants !!
Engine is useful puny jap crap but putting out some mighty decent bhp
As for the driver, god help us
- well have already bought 12 pairs of spare pants !! trackday addict said:
lol - not going to kill the class mate - one more year for the skyline whilst we try & get our head around this - mainstream events only in 2010.
Engine is useful puny jap crap but putting out some mighty decent bhp
As for the driver, god help us - well have already bought 12 pairs of spare pants !!
It'll fit right in to the FIA stuff, I'm sure puny jap crap is code for a lot of power..lolEngine is useful puny jap crap but putting out some mighty decent bhp
As for the driver, god help us
- well have already bought 12 pairs of spare pants !! I'm sure that initially it'll get your attention.
It really is killer looking John.
nearly Andy - i think the only question markis on multivalve fuel injection & whether the rules will change over the next 2 or 3 years to allow it in (if it was anywhere near competitive enough that is).
Everything else is ok ie/ cage & spec etc, turbo's are allowed in P Mod now etc.
it's original sister car ran a few 6.6's @ 215+ in 2005 so plenty of potential there but a huge learning curve for us.
Everything else is ok ie/ cage & spec etc, turbo's are allowed in P Mod now etc.
it's original sister car ran a few 6.6's @ 215+ in 2005 so plenty of potential there but a huge learning curve for us.
trackday addict said:
nearly Andy - i think the only question markis on multivalve fuel injection & whether the rules will change over the next 2 or 3 years to allow it in (if it was anywhere near competitive enough that is).
Everything else is ok ie/ cage & spec etc, turbo's are allowed in P Mod now etc.
it's original sister car ran a few 6.6's @ 215+ in 2005 so plenty of potential there but a huge learning curve for us.
I know turbos are allowed...lolEverything else is ok ie/ cage & spec etc, turbo's are allowed in P Mod now etc.
it's original sister car ran a few 6.6's @ 215+ in 2005 so plenty of potential there but a huge learning curve for us.
NHRA rules don't allow multivalves yet,but electronic fuel injection is allowed.
I've been looking..
I guess this is a V8 nissan engine not a 6pot?
So it's a 25.1E with a fully floating axle and twin frame rail?
Here's a more detailed spec minus engine - still the Nissan 350 VQ 6 pot Andy
1) It is a Vanishing Point Pro-Import / Pro-Mod chassis , full double frame rail, SFI 25.1 E. ET 5.99 and Quicker Max Weight 2800 Lbs
2) 5 spd Lenco with reverse and Taylor SFI 4.1 safety blanket. Liberty 5 speed sequential shifter w/ microswitches for gear based boost control and air switches for the air shifter.
3) Motec M800 ECU w/ CDI 8 Ignition Box.
4) Auto Meter Drivers gauge cluster w/ 5" 10,000 RPM Tach w recall, Electronic Water Temp, Electronic Brake Pressure, liquid filled boost pressure w recall, and oil pressure light.
5) SFI Certified Carbon wheel tubs and full Titanium driver seat shield.
6) Impact Racing 5 pt rotary cam belts, SFI 16.1
7) 2 Stg Halon 1211 Fire Supression System SFI spec 17.1 with 2 10Lb bottles
8) Stroud SFI 27.1 window net
9) Koni programable shock controller for rear shocks w/ data logger
10) Auto Meter Super LED shift light programed through aux output in Motec
11) ALR AMS-1000 fully programable digital boost controller w/increase and decrease solenoid, dedicated MAP sensor, launch boost control through clutch switch and CO2 over wastegates
12) Racepak V300 datalogger.
13) Trick Titanium bellhousing SFI 6.3 w/ pro-mod style reinforcements to firewall frame rails and exterior vent tube for clutch dust
14) 2 Impact crossform parachutes with stainless air launchers and pushbutton air deployment w/ manual backup deployment handle
15) Full racing wiring harness built by the wiring department at Motec USA with all deustch and mil spec connectors with custom switch panel
16) Mark Williams 3" chrome moly driveshaft with billet steel 1350 series U Bolt kit
17) Twin aluminum 2.5 lb CO2 bottles with regulators, 1 for chutes, one for shifter, boost controller, and shocks
18) Twin Rock Batteries 12 volt sealed dry cell batteries with dedicated plug and charger
19) NHRA spec battery master switch with external shut off
20) 07 350Z LED tail lights (working)
21) Adjustable aluminum wing with endplates
22) 75" import/ pro mod wheelie bars with ball bearing wheels and racepak pressure sensors
23) Vanishing Point fabricated Chrome Moly Fab 9" housing fully braced and bracketed with floater ends.
24) Mark Williams Pro Mod 3rd member with 5.00 final drive ratio with 35 spline 1350 series pinion yoke, ball bearing support, 9 1/2" pro gear, 40 spline billet spool and integrated gear oil pump
25) Mark Williams gun drilled 40 spline full floating axles with 5x5" wheel bolt pattern
26) Vanishing Point 4 link with billet brackets and telescoping x brace/ lower wishbone
27) Koni triple adjustable rear dampers with air controlled low and high speed compression and electronic controlled rebound (all through Koni controller) with hypercoil springs
28) Billet 4 pistons Mark Williams calipers with carbon/carbon brakes
29) Weld Racing Alumastar rear wheels 16x16 double beadlock.
30) Lamb double adjustable billet front struts with Lamb carbon/carbon brakes
31) Weld Racing Alumastar 15x3 1/2" Anglia spindle mount front wheels
33) Goodyear front runner tires 25x4.5-15
34) Vanishing Point fabricated 3.5 gal fuel cell w/ internal baffles an -16 fuel feed port for mechanical pump, -12 feed for priming pump and -12 return port.
35) Weldon 2015-A Fuel system priming pump (eliminates loss of prime with the mechanical fuel pump)
36) Waterman Mechanical fuel pump (2500 HP capable on Methanol) mounted to front engine plate w/ cog belt and -16 feed. Fabricated fuel "Y" to feed 4
-10 Wilson Manifolds fuel rails (2 per bank) w/ 3 Bosch Motorsports 1600cc/min injectors per cylinder (18 total)
37) Weldon Fuel Pressure regulator; 1:1 rising rate boost referenced with -12 return line
38) Innovative Turbo custom fabricated intercooler with 5" air to water heat exchanger, twin 3" inlets and single 4" outlet (all wiggans clamps) and integrated 2.5 gallon ice tank and fill and drain with custom Taylor condensation blanket (were able to pull AITs below ambient for the entire length of run wit this setup)
39) C&R Racing custom 2.5" core radiator with -12 coolant lines and SPAL puller fan and coolant pressure sensor.
40) Stewart Components Electric water pump on stand alone switch (water can be circulated between rounds to cool car faster)
41) C&R surge can on cooling system w/ air bleeds
42) Dual NTK wideband O2 sensors (1 per bank) w/ closed loop control through ECU
43) 4" Acuufab throttle body w/ integrated wiggans flange and solid linkage connected directly to throttle pedal
1) It is a Vanishing Point Pro-Import / Pro-Mod chassis , full double frame rail, SFI 25.1 E. ET 5.99 and Quicker Max Weight 2800 Lbs
2) 5 spd Lenco with reverse and Taylor SFI 4.1 safety blanket. Liberty 5 speed sequential shifter w/ microswitches for gear based boost control and air switches for the air shifter.
3) Motec M800 ECU w/ CDI 8 Ignition Box.
4) Auto Meter Drivers gauge cluster w/ 5" 10,000 RPM Tach w recall, Electronic Water Temp, Electronic Brake Pressure, liquid filled boost pressure w recall, and oil pressure light.
5) SFI Certified Carbon wheel tubs and full Titanium driver seat shield.
6) Impact Racing 5 pt rotary cam belts, SFI 16.1
7) 2 Stg Halon 1211 Fire Supression System SFI spec 17.1 with 2 10Lb bottles
8) Stroud SFI 27.1 window net
9) Koni programable shock controller for rear shocks w/ data logger
10) Auto Meter Super LED shift light programed through aux output in Motec
11) ALR AMS-1000 fully programable digital boost controller w/increase and decrease solenoid, dedicated MAP sensor, launch boost control through clutch switch and CO2 over wastegates
12) Racepak V300 datalogger.
13) Trick Titanium bellhousing SFI 6.3 w/ pro-mod style reinforcements to firewall frame rails and exterior vent tube for clutch dust
14) 2 Impact crossform parachutes with stainless air launchers and pushbutton air deployment w/ manual backup deployment handle
15) Full racing wiring harness built by the wiring department at Motec USA with all deustch and mil spec connectors with custom switch panel
16) Mark Williams 3" chrome moly driveshaft with billet steel 1350 series U Bolt kit
17) Twin aluminum 2.5 lb CO2 bottles with regulators, 1 for chutes, one for shifter, boost controller, and shocks
18) Twin Rock Batteries 12 volt sealed dry cell batteries with dedicated plug and charger
19) NHRA spec battery master switch with external shut off
20) 07 350Z LED tail lights (working)
21) Adjustable aluminum wing with endplates
22) 75" import/ pro mod wheelie bars with ball bearing wheels and racepak pressure sensors
23) Vanishing Point fabricated Chrome Moly Fab 9" housing fully braced and bracketed with floater ends.
24) Mark Williams Pro Mod 3rd member with 5.00 final drive ratio with 35 spline 1350 series pinion yoke, ball bearing support, 9 1/2" pro gear, 40 spline billet spool and integrated gear oil pump
25) Mark Williams gun drilled 40 spline full floating axles with 5x5" wheel bolt pattern
26) Vanishing Point 4 link with billet brackets and telescoping x brace/ lower wishbone
27) Koni triple adjustable rear dampers with air controlled low and high speed compression and electronic controlled rebound (all through Koni controller) with hypercoil springs
28) Billet 4 pistons Mark Williams calipers with carbon/carbon brakes
29) Weld Racing Alumastar rear wheels 16x16 double beadlock.
30) Lamb double adjustable billet front struts with Lamb carbon/carbon brakes
31) Weld Racing Alumastar 15x3 1/2" Anglia spindle mount front wheels
33) Goodyear front runner tires 25x4.5-15
34) Vanishing Point fabricated 3.5 gal fuel cell w/ internal baffles an -16 fuel feed port for mechanical pump, -12 feed for priming pump and -12 return port.
35) Weldon 2015-A Fuel system priming pump (eliminates loss of prime with the mechanical fuel pump)
36) Waterman Mechanical fuel pump (2500 HP capable on Methanol) mounted to front engine plate w/ cog belt and -16 feed. Fabricated fuel "Y" to feed 4
-10 Wilson Manifolds fuel rails (2 per bank) w/ 3 Bosch Motorsports 1600cc/min injectors per cylinder (18 total)
37) Weldon Fuel Pressure regulator; 1:1 rising rate boost referenced with -12 return line
38) Innovative Turbo custom fabricated intercooler with 5" air to water heat exchanger, twin 3" inlets and single 4" outlet (all wiggans clamps) and integrated 2.5 gallon ice tank and fill and drain with custom Taylor condensation blanket (were able to pull AITs below ambient for the entire length of run wit this setup)
39) C&R Racing custom 2.5" core radiator with -12 coolant lines and SPAL puller fan and coolant pressure sensor.
40) Stewart Components Electric water pump on stand alone switch (water can be circulated between rounds to cool car faster)
41) C&R surge can on cooling system w/ air bleeds
42) Dual NTK wideband O2 sensors (1 per bank) w/ closed loop control through ECU
43) 4" Acuufab throttle body w/ integrated wiggans flange and solid linkage connected directly to throttle pedal
It's top quality stuff there and no mistake.You have a perfect car to go fast.I'd go for the lencodrive as it'll be easier to spool that massive turbo.
Seriously with twin holes in the bonnet it needs to be a V8.I have the perfect engine..LMAO
I have 1 thing you've got anyway..lol
I'll get Slinky to give you a crash course on the AMS.
Edit,damn you have a V6..DOH!
Seriously with twin holes in the bonnet it needs to be a V8.I have the perfect engine..LMAO
I have 1 thing you've got anyway..lol
I'll get Slinky to give you a crash course on the AMS.
Edit,damn you have a V6..DOH!
Edited by redvictor on Monday 1st June 22:46
